DVR:Standard:
IP
Supported resolutions:
1080p - 1920 x 1080 px
Video outputs:
1 pcs HDMI
1 pcs VGA
Audio support:
4 Channels - Audio from cameras
Audio inputs:
1 pcs CINCH
Audio outputs:
1 pcs CINCH
Image compression method:
Smart H.265+ / H.265 / Smart H.264+ / H.264
Bitrate:
max. 40 Mbps
max. 16 Mbps Wi-Fi
Supported hard drives:
1 x 8 TB SATA, HDD : 1 TB (included)
Recording modes:
Manual, Motion Detection, Schedule
External storage devices backup:
Backup to USB drive (pendrive, external drive)
Searching and playback the records:
Records searching: by time and events type. Records playback: forward, backward, fast, slow
Advanced searching (to the one second accuracy)
1/4 channel synchronous playback
Interface:
1 x RJ-45 10/100 Base-TX 2.4 GHz Wi-Fi - IEEE 802.11 b/g/n
Network functions:
Built-in Wi-Fi module - Imou cameras support : Smart, auto-paring, Remote configuration, Remote management Full support via etwork, Remote records copying, Web Server built-in
ONVIF:
Default IP address:
192.168.1.108
Default admin user / password:
admin / -
The administrator password should be set at the first start
Web browser access ports:
80, 37777
PC client access ports:
37777
Mobile client access ports:
37777
Mobile phones support:
Port o.: 37777 or access by a cloud (P2P) Android: Free application iOS (iPhone): Free application
RTSP URL:
rtsp://admin:hasł[email protected]:554/cam/realmonitor?channel=1&subtype=0 - Main stream
rtsp://admin:hasł[email protected]:554/cam/realmonitor?channel=1&subtype=1 - Sub stream
USB:
2 pcs USB 2.0
Serial ports:
Alarm inputs / outputs:
PTZ control:
Motion Detection:
Intelligent image analysis:
Main features:
Smart, auto-paring < 120 s Alarm otifications 2x2 MIMO - MIMO technology - increases the throughput of wireless link (multiple antennas transmission) Operating range in open area : 100 m
Mouse support:
IR remote controller in the set:
Power supply:
12 V DC / 1.5 A (power adapter included)
Power consumption:
≤ 10 W (without HDD)
Operation temp:
-10 °C ... 45 °C
Weight:
1.3 kg ( Recorder with HDD )
Dimensions:
260 x 248 x 48 mm
Supported languages:
Polish, English
CAMERA:
Standard:
IP
Resolution:
1920 x 1080 - 1080p
Sensor:
1/2.8 " Progressive Scan CMOS
Lens:
2.8 mm
View angle:
108 °
White light LED illuminator range:
30 m
Audio:
Microphone built-in, Speaker built-in, Alarm siren 110 dB Audio transmission via etwork
Image compression method:
H.265 / H.264
Main stream frame rate:
25 fps @ 1080p
Network protocols:
TCP, DHCP
ONVIF:
Interface:
Ethernet : 100 Mbps Wi-Fi IEEE 802.11 b/g/n - 2.4 GHz
WEB Server:
Mobile phones support:
Access by a cloud (P2P) Android: Free application iOS (iPhone): Free application
Default admin user / password:
admin / -
The administrator password should be set at the first start
Default IP address:
DHCP
Web browser access ports:
PC client access ports:
Mobile client access ports:
Port ONVIF:
RTSP URL:
Memory card slot:
Micro SD memory cards up to 256GB support (possible local recording)
Main features:
Wi-Fi module - IEEE 802.11 b/g/n, MIMO technology - increases the throughput of wireless link (multiple antennas transmission) Motion Detection People detection D-ZOOM - Digital Zoom : 16x Built-in alarm siren LED Floodlight Full Color - colorful ight mode Light and sound alarm RESET button
Power supply:
12 V DC / 1 A (power adapter included)
Power consumption:
< 5.32 W
"Index of Protection":
IP67
Weight:
0.36 kg
Dimensions:
148 x 74 x 74 mm
General information:
Manufacturer / Brand:
IMOU
Guarantee:
2 years
